Product Description

Solar Generator 500W 600W 1000W LED Lighting Solar Multi-Outputs 1000wh Portable Power Station

Model	DY-E300A02
Battery Pack	Battery Cell	Lithium-ion Grade A battery cells
	Capacity	14.8V 33.8AH(500Wh)
	Cycle Life	>800 cycles
	BMS(Battery Management System)	Multiple Safety Protection: over-load, over-voltage, over-current, over-temperature, short circuit.
DC Output	USB/USB QC3.0	*25V2.4A; 1QC3.0 5~12V 18W(max.)*
	Type-C USB	*1Type C PD3.0 5~20V 60W(max.)**
	12V DC	*212V/5A(DC5.5x2.1mm); 112V/12A(Cigar lighter)*
	Efficiency	>93% at 70% of full loading
AC Output	Rated Output Voltage	100~240V(Customized according to different countries and regions)
(Inverter)	Output Frequency	60Hz/50Hz(Depends on factory setting according to different countries and regions)
	Output Voltage Type	Modified Pure Sine Wave
	Output Soket	Customized according to different countries and regions
	Output Power	500W
	Output Peak Power	600W (5seconds)
	Efficiency	>90% at 70% of full loading
Input	AC Charge	AC-DC Adaptor(CC/CV) 100W, (DC5.5x2.1mm)
(Recharge)	PV/Solar Charge	MPPT, Input voltage range:14~40V, 60W, (DC5.5x2.1mm)
	Car Charge	Car input voltage range:13-40V, Charge current:10A max
	Car Charge	(DC5.5x2.1mm or Cigar lighter port)
Display	Battery Status	Digital battery capacity, battery image flashing while charging
	Working Status	Discharging, Recharging,
	Output/Input Power Consumption	Digital data according to real-time powered electrical appliance.
Working Condition	Charge Temperature	0ºC~45ºC
	Discharge Temperature	-10ºC~60ºC
	Operation Humidity	10%~90%
LED Lighting	Power	5~10W(4modes of low bright, high bright, SOS, flash)
Heat Dissipation	Air cooling, Aluminum housing.
IP rate	To prevent the spraying water from vertical direction angle less than 60 degrees.
Self-consumption	<100uA(turn-off)
Dimensions & Weight	208110158MM
Certificates	PSE,CE ,FCC, RoHS,UN38.3

Deyee Portable Power Station Solar Generator 500Wh Built-in BMS PSE Certified W/ 24 Months Warranty
Features:
- DY500 is with built-in pure-sine wave inverter, which means it produces an output that is exactly the same as supplied by an AC wall outlet.
- Highly compacted design with e-vehicle lithium-ion battery pack, portable and powerful.
- User friendly, smart processor controller indiated on LED display.
- Safety priority, built-in BMS and protection circuit.
- Support 3 ways to recharge, AC 110~240V charging, Car charging, Solar Power charging(MPPT).
- Long service life 48+months.
- Provide AC output and DC output two different output modes to match the demand of different electronic products.
- Apply USB 5V, DC 12V and AC Power to home appliance(less than rated power 500Wh) and portable electronics.
- The portable solar power generator Luki500 can be used as both on-line UPS power supply and outdoor emergency standby power supply.

Solar Generator 500W 600W 1000W LED Lighting Solar Multi-Outputs 1000wh Portable Power Station

Coming to the Deyee tech , you could carry a portable solar power station right anywhere easily. If it is a smaller power station, you could just carry it by hand. If it is a large or heavy-duty solar generator, you could pick it for use in RVs, trailers, camper vans, boats, and more.
